Deye Data Logger Stick Type

The Deye Data Logger LSE-3 is a communication accessory designed to collect operating data from compatible Deye solar inverters and transmit system information for remote monitoring.

Using Ethernet communication, the LSE-3 provides a stable connection between the inverter system and the monitoring platform. It enables users to track solar system performance through the SOLARMAN platform, allowing convenient access to generation data and operational information from anywhere.

Designed with a plug-and-play structure, the LSE-3 obtains power directly from the inverter without requiring an external power supply. Its independent external design simplifies installation and replacement while helping protect internal inverter components.

The LSE-3 supports multiple communication methods including Ethernet, WiFi, GPRS and 4G versions within the Deye Stick Logger family. With IP65 waterproof protection, external status indicators and wide operating temperature capability, this data logger is built for reliable operation in various installation environments.

For solar installers, system operators and end users, the Deye Data Logger LSE-3 provides a simple and efficient solution for remote PV monitoring and distributed power station management.

Key Features of Deye Data Logger LSE-3

Ethernet Communication for Stable Data Transmission

The LSE-3 is an Ethernet-based communication logger designed to provide reliable data transmission between Deye inverters and monitoring platforms.

Its LAN communication interface supports stable network connection for PV system monitoring, helping users access inverter operating information conveniently.

Plug & Play Installation Design

The LSE-3 features a simple installation structure:

• Plug-and-play connection
• Powered directly from the inverter
• No external power supply required

This design reduces installation complexity and allows installers to complete system setup efficiently.

Remote PV System Monitoring

The LSE-3 works with the SOLARMAN platform to provide remote monitoring capabilities.

Users can monitor solar system performance through:

• SOLARMAN APP
• Web monitoring platform

This allows end users to check energy generation data and system operation status without needing direct access to the inverter.

Independent External Design

Unlike integrated communication components, the LSE-3 uses an external design.

Benefits include:

• Easier replacement when required
• Reduced impact on inverter internal components
• Simplified maintenance process

This structure improves service convenience throughout the system lifecycle.

IP65 Weather Protection

The LSE-3 features an IP65 waterproof design.

This protection helps improve reliability when installed in outdoor solar environments exposed to:

• Dust
• Moisture
• Changing weather conditions

External Status Indicator

The logger includes an external light indicator that allows users and installers to quickly identify communication and logging status.

This makes system checking easier during installation and maintenance.

Wide Operating Temperature Range

The LSE-3 is designed to operate in challenging environmental conditions with:

• Working temperature:
  -40°C to +85°C
• Working humidity:
  <90% (non-condensing)

This allows reliable operation across a wide range of installation environments.

Multiple Communication Options Across Deye Stick Logger Series

The Deye Stick Logger family supports different communication methods depending on the model.

Available communication options include:

• Ethernet
• WiFi
• GPRS
• 4G

For this product page, Solar Rains supplies the LSE-3 Ethernet version, designed specifically for LAN-based monitoring applications.

Technical Highlights of Deye Data Logger LSE-3

The LSE-3 includes the following technical specifications:

Main Benefits

For Solar Installers & EPC Contractors

The Deye Data Logger LSE-3 helps installers simplify solar monitoring system deployment.

With plug-and-play installation and direct inverter power supply, the device reduces additional wiring requirements and speeds up commissioning.

The external design also makes future replacement easier, reducing maintenance time during system servicing.

For Solar System Operators

The LSE-3 provides convenient access to PV system performance information through remote monitoring.

Operators can review inverter data through the SOLARMAN platform without needing to physically inspect each installation location.

This is especially useful for distributed solar projects where multiple systems need to be monitored efficiently.

For Residential Solar Users

For homeowners, the LSE-3 provides a simple way to stay connected with their solar system.

Through the monitoring application, users can check system operation and energy generation information directly from their mobile devices.

For Commercial Solar Projects

Commercial PV systems often require reliable monitoring solutions to maintain operational visibility.

The Ethernet communication capability of the LSE-3 provides a stable connection method for solar installations requiring consistent data transmission and remote management.

Installation

The installation of the Deye Data Logger LSE-3 is designed to be simple with its plug-and-play structure.

1. Prepare the Installation Environment

Before installation:

• Confirm the inverter supports the communication logger.
• Ensure a suitable Ethernet network connection is available.
• Check that the installation location provides safe access to the inverter communication port.

2. Connect the Data Logger to the Inverter

The LSE-3 is installed directly onto the inverter communication interface.

Because the logger receives power from the inverter, no separate power adapter or external supply is required.

After connection, the logger will begin collecting inverter operating data.

3. Connect Ethernet Communication

Connect the LAN cable between the LSE-3 and the available network connection.

The Ethernet connection allows collected inverter data to be transmitted to the monitoring platform.

4. Check Indicator Status

The external light indicator provides a quick visual confirmation of the logger operating status.

Installers can use the indicator during commissioning to verify that communication is functioning correctly.

5. Configure Monitoring Platform

After the physical installation is completed:

1. Access the SOLARMAN monitoring platform.
2. Complete the required configuration.
3. Confirm that inverter data is successfully uploaded.
4. Verify system information through the APP or web interface.

Once configured, users can remotely monitor PV system operation.

Deye

Deye is a technology company specialising in renewable energy solutions, including photovoltaic inverters and energy storage products. The company focuses on developing solar solutions for residential, commercial and industrial applications.

Through its inverter and energy storage product portfolio, Deye provides integrated solutions combining power conversion, monitoring and energy management technologies.

The Deye monitoring ecosystem, including communication accessories such as Stick Logger products, helps users connect PV systems with digital monitoring platforms for easier operation and management.
