Dyness Commercial and Industrial Battery 232 kWh – Customised Quote for Engineering Design, Import and Supply

Dyness battery DH200Y systems (232 kWh) in a large-scale solar PV installation. The Dyness DH200Y is a high-capacity (232.9 kWh) DC1000V all-in-one battery system engineered for commercial and industrial solar applications. Its modular design packs a huge 232 kWh of LiFePO₄ (LFP) storage into a single compact cabinet.

An intelligent liquid cooling system maintains uniform temperature across the packs, ensuring peak performance and long life. Each unit can output 100 kW and supports both AC/DC expansion – up to 10 cabinets in parallel (2.32 MWh total) with zero capacity loss. The DH200Y cabinet is ruggedly built (IP55, C5 corrosion grade) and includes full safety features like pack-level pressure monitoring and triple-stage fire suppression. For installation guidance, see the Dyness DH200Y installation manual.

Dyness Battery DH200Y

• Total Energy: 232.9 kWh nominal (DC), with ~90% (~210 kWh) usable energy.
• Chemistry: LiFePO₄ (LFP) CATL prismatic cells.
• Cooling: Built-in liquid cooling loop for precise temperature control.
• Built-in Management: Integrated Battery Management System (BMS) and Energy Management System (EMS) for smart control.
• Communications: Standard ports Ethernet/4G.
• Dimensions & Weight: 1055 × 1645 × 2398 mm (W×D×H, including base); ~2600 kg.
• Safety: Rugged IP55 cabinet, C5 corrosion protection, multi-level fire suppression and fault monitoring.

Key Features of Dyness Battery

• Full-scenario: All-in-one multifunctional integration, supporting PV and generator access, grid-to-off-grid switching.
• Ultimate security: Preventative fire strategy with three-level detection and TMG which ensure active firefighting remains effective in the event of a power outage.
• Flexible expansion: 71~100 kwh capacity available for single unit. Reserved DC expansion interface; Support AC expansion.
• Highly efficient and low-cost: 280Ah LFP battery with high energy density. EMS Intelligent control. Modular design, backwards output method, reduce infrastructure cost.

Main Benefits

• System Engineers: Simplified integration with built-in BMS/EMS and open protocols (Modbus TCP/CAN). Liquid cooling provides real-time thermal data for precise control and reliability. Programmable energy management allows advanced scheduling.
• EPC Contractors: Plug-and-play all-in-one cabinets cut installation time (no separate HVAC needed). Single-string design with AC/DC expansion ports makes quoting and scaling projects straightforward. Modular clusters simplify logistics and commissioning of large solar+storage sites.
• Commercial Enterprises: Delivers reliable backup power and demand management with a small footprint. High capacity supports long runtimes, improving ROI. The Dyness DH200Y’s 10-year warranty ensures long-term performance and return on investment. Its proven safety features also protect facilities and personnel.

Installation Dyness Battery DH200Y

The Dyness DH200Y (232.9 kWh) is a high-capacity commercial solar battery system designed for scalable, safe deployment. To ensure optimal performance, installers must follow key site and foundation requirements.

Site & Foundation Requirements

The DH200Y requires a dry, ventilated environment, away from corrosive gases, flammable materials, and noise-sensitive zones. Avoid areas with underground utilities or low flood elevation. The cabinet must be mounted on a concrete foundation with >3 t/m² bearing capacity, raised 300–500 mm above ground. Drainage and cable trenching must be waterproof and sized for high-current commercial wiring.

Spacing & Cabinet Layout

To support front-rear ventilation and routine maintenance:

• Leave ≥1200 mm clearance in front and ≥800 mm at the rear
• Cabinets can be installed side-by-side, supporting up to 10 units in parallel (2.32 MWh)

Anchoring & Structural Fixing

Each cabinet includes pre-designed mounting points for L-shaped angle iron brackets. Use M12 expansion bolts to anchor the unit securely. All brackets and tools (drill, marker, wrench) are provided by the installer.

Electrical Preparation

Only qualified electrical engineers are permitted to connect this system. Before wiring:

• Confirm AC/DC disconnection and polarity accuracy
• Use flame-retardant 3-phase AC cables
• Prepare copper OT/DT terminals with hydraulic crimping and heat-shrink insulation
• Maintain proper bend radius and stress relief on all cables

Wiring Tools & Components

Required tools: hydraulic crimping tool, heat gun, multimeter
Customer-supplied items: cable glands, terminals, brackets
Dyness supplies: 4G module, energy meter

Caveat: The product description and datasheet on this page may not be the most updated version. Please refer to the user manual coming with products if there are conflicts.

Dyness

Dyness is a global energy storage innovator (founded in 2017) that develops solar battery systems for residential and commercial use. The company’s product line spans low-voltage home batteries to high-voltage commercial units like the DH200Y. Dyness solar batteries use iron-phosphate cell chemistry and extensive safety monitoring; independent Dyness battery reviews note their 6000+ cycle life and robust warranty coverage.

A 10-year warranty is standard on Dyness batteries. In Australia, Dyness products (marketed by local importers) offer competitive pricing on large systems—contact your supplier for a custom quote. The Dyness battery manual and installation guide detail all specifications and procedures. With 500,000+ systems installed worldwide, Dyness batteries (including commercial solar battery models) are considered reliable and well-supported.
